Architectural drawings · detailed design

Sierra Village

Villas — Jeddah, KSA

Interactive two-page 3D simulator of the issued architectural set for Arabian Homes. Exterior massing, interiors, swimming pool, garage, guardhouse and fence are modelled to drawing levels GF ±0.00, FF +4.50, RF +8.40 and TOP +9.60. Plot types A–D, RAL 9010 plaster, travertine, wood-look cladding and HS-01/02/03 hardscape.
